Design Journal 05/03/20

To avoid the mistakes of the past and create a truely complex design, I decided it would first be important to discover the capapbilities of Google Sketch Up. The task requires abstract thinking and design, whilst most express this through curvature and parametric shapes, I decided it would be more interesting and appropriate(for the Kyza) if it was done geometrically. Inaccordance with my section I begun experimenting with 3D polygonial forms, thorough their convergence rather than extrusion.
Tinkering with extrusion occured in an attempt to turn this figure into a practical space and complex.
Solid tools were employed to the earlier feature in an atttempt to test how well it fused with curves.



Time was taken to also mess aorund wirth geometrical textures and fillaments for internal spaces, these were proving difficult to construct with vanilla Sketch Up so the Shape Bender and Weld extensions were added.


Comments

Popular posts from this blog

Design Journal 08/03/2020

Begun translating mys section into a 3D Design, currently the exterior of the upper floor and gallery is complete. Two Stairs need to be either redesgined or added, and lansdcape modelling is incomplete. Basic progression in the build is shown through the images below. The following section has been chosen for construction. Diffuse Striation The hexagonal dome was the most obious part of the section and so was intially constructed, a smaller dome being madw within to act as a sort of photography studio for the Kyza. The stright parts of the section were elongated into a trapezoidal shape to accomodate a geodesic structure at the edge. The edges expand to emphasise the experience of the widening of the space and the panoramic views of the landscape offered. The first floor was similarly articulated with basic geometric shapes and considerations for natural lighting through galss windows.  To increase the complexity of the stuructre curves were added into the roof  to metonomise...

Week 5 models Redone

In this blog post I detail my procedure for making various architectural models of my room at different scales and through different media through snapshots of the design process. Whilst initial models were made for this task, they seemed to be messy and inadequate as reflections of my skill, and so were remade as follows. The card model 1:20, the cardboard model 1:10 and the paper model 1:50, respectively have their construction shown below . Please take time to read the text and use the images as a flip book, a sort of timelapse detailing the construction. Card Model The first task allowed for the construction of a paper/card model, initially a paper model was made but it became flimsy for proper photography, hence a new one made of card was constructed. Due to isolation restrictions all materials used were recycled, with the main white card being old manilla folders , other materials included cling wrap and recycled advertising sheets. This model is made on a 1: 20 sca...

Infrographics

Data Set: Discriptive words and Images: Diversity Academia Diciple Adobe Capture: Diversity Analysis Acadmia Analysis Diciple Analysis
